DVL A100 Performance Upgrade
By upgrading the A100 to Performance version, Long Term Accuracy is improved from ±1.01% (standard) to ±0.1% (performance).
The license upgrade is an export controlled item. The goods may be subject to restrictions if re-exported from your country. Please fill out and sign the End User Undertaking
The upgrade procedure is as follows:
- Purchase this upgrade
- Send the serial number of your DVL-A100 to support@waterlinked.com
- Complete the "End User Undertaking" form linked above and secure the export license
- Perform a standard software upgrade check on your DVL (after you have received a message back from us that the license is upgraded)
Technical specifications
Acoustic / Performance
-
Transducer frequency
625 kHz
-
Transducer setup
4-beam convex Janus array
-
Transducer beam angle
22.5 degrees
-
Ping rate
1-15 Hz (adaptive to altitude)
-
Sensor assist
Integrated AHRS/IMU (Yost Labs TSS-NANO)
-
Min altitude
5 cm
- Max altitude 100 meters
- (max altitude dependent on seabed conditions, salinity levels etc.)
-
Max velocity
5 m/s
-
Velocity resolution
0.1 mm/s
- Long term accuracy ±1.01 % (Standard version)
- ±0.1 % (Performance version)
Approvals
-
CE certificate
Yes - RoHS compliant Yes
Mechanical
- Device diameter 90 mm
-
Device height
34 mm
-
Device weight (air)
0.2 kg
- Device weight (submerged) 0.13 kg
-
Depth rating
1,000 meters
- Materials PEEK (housing)
- Stainless steel 316 (back plate)
-
Operating temperature
-5 to 55 °C
Electrical / Interface
-
Input voltage
10-30 Vdc
-
Power consumption
8 W (average)
-
Power-on current surge
30 W (maximum)
- Physical interface 8 wires (pwr/serial/Ethernet)
- Side cable - 3 meter cable (PUR 6.7 mm diameter)
- Rear O-ring interface - 1 meter cable (PUR 6.7 mm diameter)
-
Indicator
Status LED (Power, Lock)
- Communication Ethernet, Serial (RS232)
-
Protocols
Water Linked API, PD4, and PD6 URL
Compact size, long-term accuracy
Standard version
±1.01%
Performance version
±0.1%
Follow the industry trend
As underwater vehicles become smaller and more accessible, the demand for affordable, lightweight sensors is skyrocketing. Stay ahead of the curve and make sure that you meet your customers' needs.
